50 MSa/s 2-Channel PXI AWG - 12-Bit Output with 64 kSa per Channel
XGY PXI-5412X is a 2-channel arbitrary waveform generator module for 3U CPCI/PXI signal generation systems. Each channel supports 12-bit output, up to 50 MSa/CH conversion, 64 kSa/CH waveform memory, and +/-5 V output amplitude.
Key technical parameters for the PXI-5412X 2-Channel Arbitrary Waveform Generator Module.
50 MSa/CH
2 channels
12 bits
VISA-based PNP driver
+/-5 V
Application fit
Use the application fit, workflow and RFQ sections below to turn a product page into a practical engineering shortlist.
Application fit
PXI-5412X 2-Channel Arbitrary Waveform Generator Module should be scoped around PXI arbitrary waveform generation, with voltage, power, interface, protection and acceptance requirements confirmed before quotation.
Application fit
PXI-5412X 2-Channel Arbitrary Waveform Generator Module should be scoped around Automated test and signal-simulation systems, with voltage, power, interface, protection and acceptance requirements confirmed before quotation.
Application fit
PXI-5412X 2-Channel Arbitrary Waveform Generator Module should be scoped around Triggered waveform generation, with voltage, power, interface, protection and acceptance requirements confirmed before quotation.
Application fit
PXI-5412X 2-Channel Arbitrary Waveform Generator Module should be scoped around External-clock waveform sequence output, with voltage, power, interface, protection and acceptance requirements confirmed before quotation.
PXI-5412X provides two arbitrary waveform output channels in a compact 3U CPCI/PXI module. The module is designed for automated test and signal-simulation systems that require triggered waveform generation, external clock support, and configurable waveform sequences.
XGY Tek engineering team can assist you with module integration, custom API hooks, and throughput optimization for the PXI-5412X 2-Channel Arbitrary Waveform Generator Module.
Get a Quote| Parameter | Specification |
|---|---|
| Channel Count | 2 channels |
| Resolution | 12 bits |
| Conversion Rate | 50 MSa/CH |
| Waveform Memory | 64 kSa/CH |
| Waveform Types | Sine, triangle, square, pulse, ramp |
| Output Amplitude | +/-5 V |
| Output Impedance | 50 ohm |
| Repeat Count | 1 to 65535 times or continuous |
| Trigger Mode | Software trigger, PXI trigger |
| DC Accuracy | +/-0.8% x setting value +/-1 mV |
| AC Accuracy | +/-1.0% x setting value x 0.707 +/-5 mVrms @ f <= 300 kHz |
| Output Frequency | Sine: 5 MHz; triangle/square/ramp: 1 MHz; pulse: 10 kHz |
| External Clock | 10 MHz to 50 MHz |
| Connector | SMA x 4: 2 analog outputs, 1 external reference clock, 1 external trigger |
| Operating System | Windows XP / Windows 7 / Linux |
| Driver Support | VISA-based PNP driver |
| Form Factor | 3U single-width, 4HP |
| Operating Temperature | Commercial C: 0 to +50 deg C; Industrial I: -20 to +50 deg C; Military J: -40 to +50 deg C |
* Specifications are subject to change without notice. Contact XGY Tek for full technical datasheet.
